JG227-30 Seal Bearing Kit Rotary Lift In-Ground 8-1/2" Cylinders
JG227-30 Seal Bearing Kit Rotary Lift In-Ground 8-1/2" Cylinders - Image 2
JG227-30 Seal Bearing Kit Rotary Lift In-Ground 8-1/2" Cylinders - Image 3
JG227-30 Seal Bearing Kit Rotary Lift In-Ground 8-1/2" Cylinders - Image 4

JG227-30 Seal Bearing Kit Rotary Lift In-Ground 8-1/2″ Cylinders

$177.88 Includes FREE standard shipping at checkout

In Stock - Free Ground Shipping

This listing is for one original equipment seal and bearing kit (JG227-30) for Rotary In-Ground Low-pressure lifts with 8-1/2″ diameter pistons. This type of seal and bearing was used on the last style Rotary introduced in 1988 before they discontinued low-pressure, high-volume in-ground lifts, on the automotive side, in the early 1990s.



This seal was used on jack numbers JG188 and JG189 with newer DTO28H side x side lifts with the I-Beam equalizer. You will also find this style seal on the Rotary model WRP90, essentially a DTO28H, but with rack and pinion equalization.

Quantity :
SKU: ALP-JG Complete seal kit Category: Tags: ,

Description

This listing is for one original equipment seal and bearing kit (JG227-30) for Rotary In-Ground Low-pressure lifts with 8-1/2″ diameter pistons. This type of seal and bearing was used on the last style Rotary introduced in 1988 before they discontinued low-pressure, high-volume in-ground lifts, on the automotive side, in the early 1990s.



This seal was used on jack numbers JG188 and JG189 with newer DTO28H side x side lifts with the I-Beam equalizer. You will also find this style seal on the Rotary model WRP90, essentially a DTO28H, but with rack and pinion equalization.

The gland ring at finished floor is made of cast iron and has a “JG512” stamped on the top with 8 bolts plus a bleeder screw. If your lift has any of these “JG” numbers then this IS your kit. lf your lift has an aluminum gland ring with 6 holes and a 7th for a bleeder, then this is NOT your kit. Please see our other listings or contact us at (331) 442-9150 before ordering.

This kit not only consists of the seal but it also includes all the other replacement parts: the seal including the o-ring, nylatron bearings, 8 new cap screws and a bleeder screw.

If you are resealing a both pistons on one lift, please order two (2) kits.

If you are not sure if this is the correct item please contact us at (331) 442-9150.

We Welcome your Inquires. All responses from owner/operators!

Additional information

Weight 5 lbs
Dimensions 10 × 10 × 5 in
